วาลว์ลมใช้มือปิด

TUBE FITTING HAND VALVE

The hand valves are designed to turn on and off the airflow.
TWo-way and three-way valves are available for all models.
Three-way directional control valve releases the residual internal pressure on the
Output side when manually closed
G-Thread type also available.

Fluid Type	Air (No other type of gas or liquid)
Working Pressure Range	0~150PSI	0~9.9KgF/cm2(0~990KPa)
Negative Pressure	-29.5 in Hg	-750mm Hg(10 Torr)
Working Temperature	32~140°F	0-60℃

- -

HVFF	MODEL(φD-T)
	Tube(Metric)-Thread(R)
	HVFF 06-06
	HVFF 08-06
	HVFF 08-08
	HVFF 10-08
	HVFF 10-10
	HVFF 12-10
	HVFF 12-12

- - -

HVSF	MODEL(φD-T)
	Tube(Metric)-Thread(R)
	HVSF 01-06	HVSF 02-12
	HVSF 02-06	HVSF 03-12
	HVSF 03-06	HVSF 04-12
	HVSF 01-08
	HVSF 02-08
	HVSF 03-08
	HVSF 02-10
	HVSF 03-10
	HVSF 04-10

- - -

HVFS	MODEL(φD-T)
	Tube(Metric)-Thread(R)
	HVFS 06-01	HVFS 12-02
	HVFS 06-02	HVFS 12-03
	HVFS 06-03	HVFS 12-04
	HVFS 08-01
	HVFS 08-02
	HVFS 08-03
	HVFS 10-02
	HVFS 10-03
	HVFS 10-04
