KITZ AKTFLL / CTFLL Type 600 Brass Ball Valves (Full Bore)
คุณสมบัติสินค้า:
KITZ AKTFLL / CTFLL Type 600 Brass Ball Valves (Full Bore) Type 600 Brass Ball Valves (Full Bore) AKTFLL Threaded end to ASME B1.20.1 CTFLL Solder joint end to ASME B16.18 W.O.G. non-shock 4.12 MPa (600 psi), Saturated steam pressure 1.03 MPa (150 psi) Maximum pressure temperature limitation: 150 psi at 300·F
Size
หมวดหมู่ : KITZ คิตาซาว่า วาล์ว(Valve KITAZAWA) , Ball Valves ,
แบรนด์ : KITZ
Share
KITZ AKTFLL / CTFLL Type 600 Brass Ball Valves (Full Bore)
Type 600 Brass Ball Valves (Full Bore)
AKTFLL
Threaded end to ASME B1.20.1
CTFLL
Solder joint end to ASME B16.18
W.O.G. non-shock 4.12 MPa (600 psi), Saturated steam pressure 1.03 MPa (150 psi)
Maximum pressure temperature limitation: 150 psi at 300·F
