Enclosure : IP65 : Water-proof and dust-proof enclosure. Material : Plastic cover (material: ABS Impact Resistance) Motor : Insulation class F. Built-in thermal protection prevents motor burning out. AC motor:125±5℃/257±9℉
Duty Cycle : BM-2:30% duty cycle Working Conditions : Ambient temperature:-30℃ to +65℃ / -22℉ to +149℉ The humidity:30% to 95% Position Indicator : All models have continuous mechanism position indicator on the top of actuator cover. Gear Train : Gear trains have been already lubricated sufficiently with anti-high temperature lubricant at the factory. Conduit entrance : Standard : 1/2" PS Optional : 1/2”NPT or M20 Various voltage : AC 220/380/440V, 3-Phase AC 110/220V, 1-Phase Working angle : Standard : 0-90°
